规格 | 量程 | 解析度 | 准确性 |
直流电压 | 6V/60V/600V | 0.001V/0.01V/0.1V | ±(0.5%+5) |
1000V | 1V | ±(0.8%+4) |
交流电压 | 6V/60V/600V | 0.001V/0.01V/0.1V | ±(0.6%+5) |
750V | 1V | ±(0.8%+4) |
交流电流 | 60A/600A/1000A | 0.01A/0.1A/1A | ±(2.0%+8) |
浪涌电流 | 60A/600A/1000A | 0.01A/0.1A/1A | ±(5.0%+60) |
电阻 | 600Ω/6kΩ/60kΩ/600kΩ | 0.1Ω/0.001kΩ/0.01kΩ/0.1kΩ | ±(0.8%+3) |
6MΩ/60MΩ | 0.001MΩ/0.01MΩ | ±(2.0%+5) |
电容 | 9.999nF/99.99nF/999.9nF/9.999µF/ | 0.001nF/0.01nF/0.1nF/0.001µF | ±(3.0%+5) |
99.99µF/999.9µF/9.999mF/99.99mF | 0.01µF/0.1µF/0.001mF/0.01mF | ±(3.0%+5) |
有功功率 | 3.0W/100.0W/4000W | 0.01W/0.1W/1W | ±(3.0%+5) |
10.0kW/100.0kW/750kW | 0.01kW/0.1kW/1kW | ±(3.0%+5) |
视在功率 | 3.0VA/100.0VA/4000VA | 0.01VA/0.1VA/1VA | ±(3.0%+5) |
10.0kVA/100.0kVA/750kVA | 0.01kVA/0.1kVA/1kVA | ±(3.0%+5) |
无功功率 | 3.0VAr/100.0VAr/4000VAr | 0.01VAr/0.1VAr/1VAr | ±(3.0%+5) |
10.0kVAr/100.0kVAr/750kVAr | 0.01kVAr/0.1kVAr/1kVAr | ±(3.0%+5) |
功率因数 | 0.3～1 | 0.001 | ±(2.0%+5) |
频率 (V) | 99.99Hz/999.9Hz/9.999kHz | 0.01Hz/0.1Hz/0.001kHZ | ±(1.5%+5) |
>10kHz | 0.01kHz | ±(1.5%+5) |
频率 (A) | 99.99Hz/999.9Hz | 0.01Hz/0.1Hz | ±(1.5%+5) |
>1kHz | 0.001kHz | ±(1.5%+5) |
频率 (W) | 40～1kHz | 0.1Hz | ±(0.5%+1) |
频率 (KW) | 40～1kHz | 0.1Hz | ±(0.5%+1) |
频率 (Hz/Duty) | 9.999Hz/99.99Hz/999.9Hz/9.999kHz | 0.001Hz/0.01Hz/0.1Hz/0.001kHz | ±(0.3%+5) |
99.99kHz/999.9kHz/9.999MHz/ | 0.01kHz/0.1kHz/0.001MHz | ±(0.3%+5) |
占空比 | 0.1%-99.9% | 0.10% | ±(3.0%+3) |
谐波 测量 45Hz～65Hz (基本的) | 谐波数：1 | | ±(3.0%+10) |
谐波数：2～6 | | ±(3.5%+10) |
谐波数：7～8 | | ±(4.5%+10) |
谐波数：9～10 | | ±(5.0%+10) |
谐波数：11～15 | | ±(7.0%+10) |
谐波数：16～20 | | ±(10%+10) |
